GRP/FRP pipe machine/equipment

mainly used to produce and manufacture the small pipe of fiber reinforced composite and the tank winding molded products, such as composite insulator, epoxy sleeve, CNG compressed gas cylinder, gas cylinder of respirator, putamina for water treatment, FRP tank for water treatment and etc. This production line is characterized by the high precision of winding line, high productivity, low energy-consuming, easy installation, adjustment and maintenance. It adopts the industrial computer control, so the usage and operation are very convenient. PIPE WINDING MACHINEEquipment No Item Name FWLM600-1 FWLM300-3 FWLM500-2 Product diameter , ID mm DN50-DN600 DN20-DN300 DN50-DN500 Number of winding shaft,(product number manufactured in one time) 1 3 2 Winding angle 10 º90 º 10 º90 º 10 º90 º Product length ,mm ≤3200 or according to customers requirements ≤3200 or according to customers requirements ≤3200 or according to customers requirements Rotating speed of main shaft ,r/min ≤120 ≤120 ≤120 Transmission method Pinion, rack + linear guide rail Pinion, rack + linear guide rail Pinion, rack + linear guide rail Control method manualsemi automaticautomatic manualsemi automaticautomatic manualsemi automaticautomatic Coordinate speed of vehicle,m/min 60 60 60 Precision of lining up yarn ,mm ±0.2 ±0.2 ±0.2 Repositioning accuracy ,mm 0.02 0.02 0.02 Max speed of pulling yarn ,m/min 75 75 75 Max width of yarn tape ,mm 50 50 50 Winding type Reciprocating cross, hoop direction Reciprocating cross, hoop direction Reciprocating cross, hoop direction Winding roving capacity,each 15 36 30 Resin type Unsaturated polyester, epoxy resin Unsaturated polyester, epoxy resin Unsaturated polyester, epoxy resin Yarn framechoose one from inner pulling or outer taking Tension adjustable yarn frame of mechanical type Tension adjustable yarn frame of mechanical type Tension adjustable yarn frame of mechanical type Impregnation groove,(stainless steel Roller impregnation with heating system Roller impregnation with heating system Roller impregnation with heating system Production capacity ,kg/h 100 150 200 Total installed capacity , kw 9.5 not contain the heating cure station 10.5 not contain the heating cure station 11.5 not contain the heating cure station Areas covered by production linelength × width × heightm 7.5×9×2.5 7.5×9×2.5 7.5×9×2.5 s
